Classic wooden boat plans is a collection of established wooden boat designs ranging from the early 1900’s to about 1970. Some of our own designs are Banshee, Custom Barrelback 19 and the Deep V inspired by the Donzi Sweet 16, Bantam. Other plans include Chris Craft, Hacker, Gar Wood, Riva, Switzer, barrel back, Baby Bootlegger, Flyer, Teaser.
Lorraine Hacker Designed 16'
Lorraine Hacker Designed 16'
Lorraine is a sleek 16 footer designed by J Hacker utilising a 3 cylinder 2 stroke Pierce- Budd motor of approximately 25 hp. A twin blade propeller of 16” and a pitch of 22” is said to have provided a top speed of 30 mph. Lorraine has a max beam of 56” or just over 4 1/2 feet. Buyers looking to install similar sized motors can email us for fitment and custom engine beds at no additional cost.
Plans include all frames and floor timbers, hatch assembly, transom assembly, all fully lofted and a building jig for ease of set up. Included are 2 3D files to aid in part recognition and can be measured off directly for checking. As with all our plans, Lorraine can be scaled up proportionally by changing the frame spacing’s. Any increase beyond 10% will need the plans scaled up proportionally during printing. Fully lofted files use ARCH E paper size, dimensioned assembly plans are all A3.
All plans provided as PDF files that must then be printed at 100%, full scale.
